10KW Hybrid Off grid Solar System Installation In Australia


The 10kW solar power system is a popular choice for residential and small commercial properties in Australia.

It comprises solar panels, solar inverter, solar battery, mounting equipment, and other necessary components.

This system size is designed to generate clean and renewable electricity from sunlight, reducing your reliance on grid power and lowering your carbon footprint.

System Component

Product PictureProcut NameSpecificationQuantity

Solar Inverter

Rated Power: 5KW

DC Input Voltage: 48V

AC Output Voltage: 230V

Mppt Inpute Current: 22A

PV Input Voltage Range: 150V-500V

Size: 556*345*182 mm

Weight: 19.2 kg

2 pcs

Solar PanelMax. Power: 550wp

Voltage: 50.1V

Max. Working Current: 13A

Size: 2256*1133*35 mm/pcs

Net Weight: 28.5 kg/pcs

20 pcs

Solar Battery

Type: LiFePo4

Voltage: 48V

Capacity: 50Ah

Size:  660*480*165 mm

Net Weight: 49 kg

1 pcs

Mounting SystemApplicable: Caigang tile trapezoidal tile, corrugated tile roof

Installation quantity: 2 vertical

Angle not adjustable

Weight: 15 kg

10 set

PV Cable


Red 100m+Black 100 m


The energy generation of a 10kW solar power system depends on various factors, including location, orientation, tilt angle, shading, and weather conditions.

On average, in Australia, a well-designed and properly installed 10kW solar power system can generate around 40-50 kWh per day. This energy production can offset a significant portion of your electricity consumption, resulting in reduced energy bills and long-term cost savings.

It reduces your reliance on grid electricity, which helps protect against rising energy prices. Secondly, by generating your own clean energy, you contribute to reducing greenhouse gas emissions and combating climate change.

Additionally, in Australia, solar systems are eligible for government incentives such as Small-scale Technology Certificates (STCs) or rebates, which can help offset the upfront costs of installation.
