The 15KW Home Wind Generator System includes a mono solar panel with a maximum power of 550W, an off-grid inverter with a power of 15000W, a wind controller with a rated input power of 5KW and a wind generator with a rated power of 5KW. The system has a daily power generation capacity of 35kwh based on a wind speed of 12m/s for 7 hours per day, and a design capacity of lead-acid batteries at 43.2kwh. With Q235 hot-dip galvanized tower and lead acid batteries, the system is designed for long-term and reliable performance for residential use.
Company Profile:
Our company is a leading provider of renewable energy solutions, specializing in the design and installation of efficient home wind generator systems. With over a decade of experience in the industry, we have established ourselves as a trusted supplier of high-quality and reliable products. Our team of experts is dedicated to promoting sustainability and reducing carbon footprints by offering innovative and environmentally friendly energy solutions to our customers. We are committed to providing exceptional customer service and ensuring that our products meet the highest standards of performance and durability. Choose our company for a sustainable energy solution that will power your home with clean and reliable electricity.
Our company is dedicated to providing eco-friendly energy solutions for residential homes. With a focus on sustainability and reducing carbon footprints, we offer top-of-the-line 15KW Home Wind Generator Systems. Our team of experts has carefully designed and tested these systems to ensure maximum efficiency and durability. By harnessing the power of wind, our generators provide a reliable source of clean energy for your household while significantly reducing your electricity bills. Invest in our Home Wind Generator System today and make a positive impact on the environment while enjoying the benefits of renewable energy.
According to the standard solar irradiance of 1000W/㎡, battery temperature of 25℃ and AM=1.5, with an averageillumination time of 4 hours, a daily power generation capacity of 35.2kwh;
Calculated based on a wind speed of 12m/s at 7 hours per day, the daily power generation capacity is 5kw*7h=35kwh;
The design capacity of lead-acid batteries is 43.2kwh;
The total gross weight of the list is approximately 2000KG, and thevolume is 8m³.
MODEL | PRODUCT NAME | PRODUCT NO. | DESCRIPTION | QUANTITY | UNIT |
JH-OA-15KWK1 | MONO Solar Panel | JH-DQ-550K1 | Max.Power:550wp Voltage: 51.2V Max.Working Current: 13A Size: 2256*1133*35mm Net Weight: 28.5kg/pcs | 16 | pcs |
Off Grid Inverter | JH-NA15KK1 | Rate Power: 15000W AC Output Voltage: 220V Phase: 1 Frequency:500Hz/60Hz | 1 | pcs | |
Wind Controller | JH-GA-5KK2 | Rated input power: 5KW Battery Rated voltage: 240V Size: 360*440*195mm Weights: 15.5KG | 1 | pcs | |
Wind Generator | JH-WA-5KK1 | Rated battery voltage: 48V Rated power: 5KW Starting wind speed: 3m/s Rated wind speed: 10m/s Maximum wind speed: 35m/s Wind wheel diameter: 4.8M Blade height: 2.3M Host net weight: 250KG | 1 | pcs | |
Tower | / | Q235 hot-dip galvanized with plastic spraying Cage with pre-buried parts Length: 3m | 1 | pcs | |
PV Cable | JH-QA1-F4 | 4mm²(black+red) | 200+200 | m | |
PV Bracket | / | Ground/cement flat roof 2 pieces | 8 | set | |
Lead Acid Battery | JH-CF-100K1 | Voltage: 12V Capacity: 100Ah | 18 | pcs |
